Total power required | 45.5 kw |
| Working Station | 30 sets |
| Max.shaft diameter | 80mm |
| Motor power | 2*15KW |
Dimensions (L*W*H) | 14m*1.6m*1.5m |
Overall packing s hipment | Total 2X40gp container |
Working hours per day | 8 to 16 hours |
Set up t ime | 20 mins |
Line d irection | Left to right while facing operator panel |
Machine frame | H-BEAM frame |
Variable line speed | 0-8m/min |
Material loading system | Manual |
MAJOR EQUIPMENTS we designed as below:
A - DECOILER.....................................................................PASSIVE DECOILER with Leveling
B-PUNCHING UNIT.....................................................................SERVO FEEDING AND PRESS MACHINE PUNCHING
B- INFEEDER APPLICATOR.........................................TO GUIDE MATERIAL
C- ROLL FORMING UNIT............................TO ROLLING THE DRAWING PROFILE
D-CUTTING SYSTEM...................................FLYING SAW CUT TO LENGTH
E- OUTPUT TABLE...... ......................SUPPORT THE FINISHED PRODUCTS
MACHINE WORKING FLOW
