YD-GR-01
YTSING
| Parameter | ||
| Finished Product | Thickness | 1.2-1.5mm |
| Material | Galvanized/Carbon Steel Coil | |
| Effective width | 50mm | |
| Machine Main Specification | ||
| Coiler | Dimensions for decoiler | 500*800*1000mm |
| Capacity | 5 tons | |
| Mandrel expansion by | Manual | |
| Roll forming part | Dimensions for rollformer | 11000*1800*1500mm |
| Structure | Column | |
| Working Station | 24 working stations | |
| Roller Material | GCr15,Double machining | |
| Shaft Diameter | 76mm | |
| Driving System | Gearbox driving | |
| Main power | 18.5KW | |
| Cutter Material | Saw blade | |
| Power of hydraulic station | 3.0KW | |
| Cutting System | Hydraulic and Flying | |
