| NO | TYPE | SPECIFICATION | |
| 1 | RAW MATERIAL | TYPE | Galvanized steel material |
| Thickness | 0.4-0.5mm | ||
| 2 | DECOILER | Type | Hydraulic decoiler |
| Max Coil width can be loaded | 1300mm | ||
| Max coil weight | 3000kg | ||
| Mandrel face length | 300mm | ||
| Inner diameter of coil | 480-630mm | ||
| Max out diameter | 1800mm | ||
| Material of shaft | GCR45 steel | ||
| 3 | ROLL FORMER | Work station | 28sets |
| Max. roll shaft diameter | 76mm | ||
| Power | 11kw | ||
| Max production speed | 20mtr./min | ||
| Transducer | yaskawa | ||
| Structure | Column | ||
| Transmission | chain | ||
| Roller Material | GCR15, CNC lathes, double machining, quenched 58-62 | ||
| 4 | HYDRAULIC CUTTING | Power | 3kw |
| Cutting mould material | Cr12 MOV, quenched HRC58-62 | ||
| 5 | OUTPUT TABLE | Specification(W*H) | 3000mm*1500mm |
| Stacking length | According to your demands | ||
